KEY SPECIFICATION

DIMENSIONS: Width 600mm

PERFORMANCE:

Energy Class B

Grease absorption A

Annual Consumption 24kWh/yr

Max. Extraction 570m3/h

Noise level 70dB

INSTALLATION: 32A Fuse rating

HOB FEATURES

• Black glass with black extractor grille
• Frameless
• Suitable for flush or inset installation
• Invisi touch control with direct access
• 10 power levels [0-9 and Booster]
• Booster function on all zones, including Auto Boost mode
• Timer function per zone /minute minder
• Bridge function
• Auto boost function
• Child safety lock
• Memory recall function
• Residual heat indicators
• Anti-overheat protection
• Anti Over flow
• Automatic safety shut-off
• Auto pan detection
• Preset temperature setting [keep warm 70°C]

COOKING OUTPUT

• 190mm 2100W/3000W
• 190mm 2100W/3000W
• 190mm 2100W/3000W
• 190mm 2100W/2100W

DOWNDRAFT FEATURES

• Touch control
• 10 Speeds [0-9 and Boost]
• Auto 10 - 60 minute timer, switch-off after 10mins
• Ducting spigot size 150mm
• Can be ducted or recirculated
• Motor included

PLASMA FILTER

• Plasma filter with ESD
• Helps to filter against, cooking odours, airborne viruses, bacteria, fungi, cigarette smoke, VOCs, pollen, fine dust and pet allergens
• For use in recirculation mode
• 200 x 90 Inlet diameter
• Max. extraction 1000m3/h
• Fully recyclable through the PlasmaMade return system
• Power consumption 6w/h
• 10/15 year lifespan
• Easy assembly
• Can be retrofitted
• Does NOT require the charcoal filter to be changed
• 2 year warranty [5 years after registering]
• UK plug included
